U.A.N.V.B.-S.C. Raptor Night Vision Binocular | New Zealand Night Raider

Ultra-Light Articulating Night Vision Binocular – Single Control

The U.A.N.V.B.-S.C., known as the “Raptor”, is a full-feature professional night vision binocular engineered for maximum strength, minimal weight, and operational versatility. Designed with a cutting-edge carbon fiber reinforced thermoplastic composite, this hybrid injection-molded material surpasses traditional polymers and rivals 6061-T6 aluminum in tensile strength — without the added weight.

Built from lessons learned across previous Nocturn Industries platforms and refined through direct user feedback, the Raptor delivers streamlined control, rugged durability, and mission-ready performance.

Single Control System

The Raptor features an ergonomic single-turn control knob engineered for intuitive operation:

Power and manual gain adjustment
Double-tap activation of IR illuminator
Adjustable IR brightness while active
Enable/disable auto-off when stowed
Integrated IR status indicator
Low battery indicator

Compatibility

The Raptor is built for maximum flexibility and system integration:

Compatible with standard EGAC MX-11769 (pigtail) tubes
Compatible with 3-pad MX-11769 tubes
Compatible with MX-10160 tubes (loss of gain control)
Works with PVS-14 optics and accessories
Interchangeable image tube pod with U.N.V.M. “Talon”

Key Features

High-strength hybrid fiber reinforced injection molded polymer housing
Manual gain control
Toolless knobbed IPD stops
Low-profile IPD adjustment knobs
User-adjustable pod tension
Individual pod on/off when articulated
On-board battery compartment
External power port (LEMO 00B / 2-pin)
IR illuminator with adjustable brightness
Low battery indicator
Designed to meet and exceed IP68+ and MIL-STD-810H standards
Designed and assembled in the USA

Specifications

Housing Weight	5.01 oz / 0.31 lbs / 142 g
Device Weight (Standard Configuration)	20.04 oz / 1.25 lbs / 568 g
Device Weight (Lightweight Configuration)	16.01 oz / 1.00 lb / 454 g
Tube Type Compatibility	18mm MX-11769 (EGAC pigtail or 3-pad), MX-10160 (loss of gain control)
Battery Types	CR123A or AA (on-board), AAA (on-board)
Battery Runtime	26+ hours (CR123A or AA) 10+ hours (AAA on-board) 100+ hours (Optional 4x CR123A external battery pack)
External Power Port	LEMO 00B (2-pin)
Finish Options	Matte Black, H-Series Cerakote (Coyote Brown, OD Green)
Environmental Rating	Exceeds IP68+ and MIL-STD-810H

Runtime estimated at room temperature. Standard configuration based on mil-spec optics and Photonis IITs with battery. Lightweight configuration based on RPO 4.0 optics and Photonis IITs with battery.

Warranty

Every Nocturn Industries housing is backed by a lifetime repair or replacement warranty.

We don’t just build durable systems — we stand behind them forever.

Lifetime repair or replacement of all housing components
No questions asked
Does not cover damage to intensifier tubes or lens assemblies

Built for Professionals

The Raptor combines ultra-lightweight construction, ruggedized durability, modular compatibility, and streamlined control into a single mission-ready system. Designed and assembled in the United States, it delivers professional-grade performance for demanding night vision applications.
